APB100/150PB

Adjustable Elevated Post Base

APB features a post mounting plate on a screw allowing it to be adjusted to a specific standoff height ranging from 100-150mm.

Suitable for post sizes 100 x 100mm to 200 x 200mm.

Technical Data Sheet
CE Marking
CE Marking
ETA
ETA
New
New
Service class 2
Service class 2
Acier RAL 9005
Acier RAL 9005
Outdoor
Outdoor
EPD
EPD
Electro-galvanized steel
Electro-galvanized steel
APB100_150PB_SSTBP_homepage_PL_pl

Product Details

Images

APB100150PB face H.jpg

Features

Material

  • Pre-galvanised mild steel.

Benefits

  • Simple, height adjustable

Application

Header member

  • Solid or glulam timber.

Applications

  • Post support.
  • Garage ports.
  • Pergola.

Technical Data

Product Dimensions

Dimensions

Product Dimensions
Product Dimensions
ReferenceConnector Dimensions
Dimensions and drill holes[mm]Top plate holesBottom plate holesOther
A[mm]B[mm]D[mm]E[mm]F[mm]G[mm]Thickness[mm]RoundRound Weight[kg]
Ø12Porteur
APB100/150PB100100130130100-150204441.2

Product capacities - Timber to concrete

ReferencePost base capacity
Number of FastenersCharacteristic capacities - Timber C24[kN]
On postOn concreteR₁,ₖR1,k*
QtyTypeQtyType
APB100/150PB4.0Ø104.0Ø10**58/kmod^0,571.9

*The published characteristic capacity is based on medium term load duration and service class 3 according to EC5 (EN 1995). For other load duration and service class, please refer to the ETA to get more accurate capacities

** Refer to the Simpson Strong-Tie anchor product range for suitable anchors. Typical anchor solutions depend on the concrete type, spacing and edge distances.

Installation

Installation

Fixing

  • M12 Bolts

Installation

Fix to the foundation with concrete/mechanical anchor system. Fix to the post using M10 coach screws.

Fixation pied poteau APB100/150 sur support rigide

Certification

European Technical Assessment (ETA)

eta-07-0285-2021-12-09.pdf
No history available

Environmental Product Declarations (EPD)

epd-certificate-sst-connectors

CAD and BIM Library

Nailing Pattern

APB100/150PB
